Pre-treatment

Pre-treatment plays very important role in efficient and safe operation of the purified water generation system. The pre-treatment units are modular and are designed according to the raw water characteristics.

Media Filtration, Softener & Ultrafiltration Plant

All pre-engineered standard packaged plants have FRP vessels with automatic operation facility. Manually operated filters can be provided on request. Automatic disc filtration in lieu of media filter is also available as an option.

Softeners are made using uniform particle size IX resin which gives highest regeneration efficiency and lowest outlet hardness. As a standard feature the Softeners are supplied with automatic operation facility.

All UF plants are fully automatic and can be designed as dead-end plant operation or with continuous bleed depending on feed water characteristics.

RO-EDI

Hydropure offers standard packaged RO-EDI systems from 250 lph to 50,000 lph capacities for Pharma applications. Customized and larger capacities RO Plants are also available on request.

Standard package systems include chemical dosing stations, 5 micron cartridge filters and RO Block. The RO Block typically has two passes in which the Pass 1 permeate is treated through Pass 2 RO. The RO Membranes are housed in electro polished SS316L RO tubes fitted with SS316L piping, valves and fittings. The RO permeate is purified further by an EDI unit to achieve PW water quality.

An independent skid mounted CIP System is provided for RO cleaning and the hot water RO also includes a heat sanitisation system; it has an option of heating either by steam or by electricity.

Hydropure also offers next generation No Added Chemicals PW Generation System as an option. The advanced design offers advantage of chemical free operation of the RO.

Post EDI Ultrafiltration

A post EDI UF System with 6000 Daltons Molecular Weight Cutoff membranes serves to produce highly purified water having a compliance with low endotoxin values.

A post EDI UF can have a TOC reduction UV with 194 nm wavelength or 254 nm wavelength for bacterial control as an option.
